Payment method, equipment warranty scope and maintenance ：
1、Payment ：50% deposit，50% balance before shipping；
2、 If the equipment is man-made damage, natural disasters, non-equipment quality factors and force majeure damage is not within the warranty ；
A． Hardware Training Services
1． Laser principle introduction ；
2． Laser equipment system components
3． Operating equipment program ；
4． Optical device maintenance ；
5． Treatment of common faults 。
B．Software Training service
1． Basic knowledge of computer ；
2．Common drawing software CORELDRAW, etc.；
3． How to edit the marking software ；
4． Powerful marking software ；
5． The use of scanners 。
Type：standard machine
Laser power：10W/20W/30W/50W
Marking range：110X110MM（optional）
Marking speed：250characters/s（Roman font，h=1mm)
Power stability（8h)：<±1%rms
Beam quality：<2M2
Min characters： 0.3mm
Min line width：30um
Power supply：220V±22V/50Hv/2.5A
Working temperature：15℃-35℃
Power comsumption： <0.5kW
Pulse repetition frequency ：20-200KHz
Cooling way：air cooling
| Model | CY-GQ20 | |
| parameters | Engraving range | 110mmx110mm （optional 150*150mm 175mm*175mm） |
| Engraving speed（Roma format h=1mm） | ＜15000mm/S | |
| Engraving min character | 0.1mm | |
| Engraving min line width | 0.01mm | |
|
features |
Laser Type/Wavelength | Fiber laser machine/1064nm |
| Laser power | 20w | |
| Power stability(12h) | ＜±1%rms | |
| Beam quality M2 | ＜1.5 | |
| Pulse repetition frequency | 100kHz | |
| Laser safety rating | CIassIV | |
| Other parameters | System safety rating | IP54 |
| Cooling way | Air cooling | |
| Working temperature | 15℃-35℃ | |
| Power supply | 220V±22V/50Hz/2.5A | |
| Power supply | ＜1KW | |
| Power supply | 550mmx900mmx1200mm（besides non standard machine） | |
| Weight | 100kg | |
